Choose the right hinge before you replace it.
Lazy Susan cabinet hinges must match the door connection, cabinet construction and overlay—not just an angle. Identify what the hinge connects, compare the mounting details, then choose self-closing or soft-close operation.
A 135° hinge is not automatically a space-saving substitute for a 165° hinge. Different corner layouts can require different hinge geometries, and a folding door can use more than one type of connection.
Types of Lazy Susan cabinet hinges: identify the connection
Open the doors and look at both ends of each hinge. Corner cabinets do not all use the same door arrangement. The hinges that move a door are also separate from the bearings or pivot hardware that turn the storage shelves. For a blind-corner layout, check the cabinet footprint, filler and access opening separately from hinge selection.
Door to cabinet
This connection carries a door from the cabinet body or its specified mounting arrangement. Check the cabinet construction, overlay, mounting plate and clearance throughout the opening movement.
Door to door
A folding or bi-fold front has a joint between two door panels. That joint needs the correct folding-door geometry; it is not automatically served by the same hinge that attaches the first panel to the cabinet.
135° vs 165° Lazy Susan hinges: what matters?
Across hinge systems, an angle can describe the intended corner geometry or the opening movement. Read the specification for the exact model. Do not assume every product labeled 135° attaches in the same way or that changing to 165° preserves the existing installation.
| Model | Closing action | Selection checkpoint |
|---|---|---|
| 135° Lazy Susan | Spring-assisted self-closing | Match the required corner geometry. Do not choose it only because a wider-opening door hits a wall. |
| 165° self-closing | Spring-assisted; no soft-close damping | Compare for wide-opening access when the mounting, overlay and full door movement fit. |
| 165° soft-close | Damped closing action | Compare when you need soft closing and the complete hinge-and-mounting arrangement is compatible. |
All three Berta listings below specify frameless, full-overlay applications. That does not make them interchangeable or establish compatibility with a face-frame cabinet. On smaller screens, swipe the comparison table to see every column.
Shop Berta Lazy Susan cabinet hinges
Compare the three models below with your existing hinge and cabinet. Each listing is a 20-piece pack of individual hinges with installation screws—not 20 pairs or a guaranteed complete kit for 20 doors.
135° Lazy Susan Hinges
For a corner installation that matches this model’s geometry and mounting requirements.
- Frameless · Full overlay
- Spring-assisted self-closing
- 20 individual hinges + screws
165° Self-Closing Hinges
A wide-opening option with spring-assisted closing, without a soft-close damper.
- Frameless · Full overlay
- 35 mm cup · Listed 13 mm cup depth
- 20 individual hinges + screws
165° Soft-Close Hinges
For a compatible wide-opening installation where controlled closing is a priority.
- Frameless · Full overlay
- 35 mm cup · Listed 13 mm cup depth
- 20 individual hinges + screws
Check the product page for current price, availability, specifications and pack contents before ordering. Cup dimensions alone do not confirm replacement fit.
What to measure before buying replacement hinges
Keep the old hinge and mounting plate until the replacement is confirmed. Record the following for each different hinge connection in the corner assembly.
- Connection and cabinet construction. Identify door-to-cabinet versus door-to-door mounting, and whether the cabinet is frameless or has a face frame.
- Overlay and closed-door position. Measure how far the door covers the cabinet edge and record the gaps between adjoining fronts.
- Cup bore and door thickness. Measure the bore diameter, existing bore depth and door thickness. Verify the replacement’s permitted door range and drilling instructions.
- Hole pattern and edge distance. Record fixing-hole centers and the distance from the door edge to the cup bore. A matching 35 mm cup does not guarantee matching screw locations.
- Mounting plate and hinge attachment. Check plate height, fixing positions and the hinge-to-plate connection. Do not assume an old plate accepts a different brand or model.
- Movement and load. Check both doors, handles and neighboring surfaces throughout the full swing. Confirm hinge quantity and load requirements for the complete assembly rather than copying a generic two-hinge rule.
Self-closing vs soft-close: choose after confirming fit
Self-closing uses spring action to help bring the door shut. Soft-close adds damping to slow the closing movement. A self-closing hinge without a damper should not be purchased as a soft-close hinge.
Berta’s 165° self-closing and 165° soft-close listings both specify a 35 mm cup diameter and 13 mm cup depth. Soft-close does not automatically mean a deeper cup. You still need to compare the hinge body, plate, screw pattern, door-thickness limits and clearance.
For more on closing mechanisms, read soft-close vs standard cabinet hinges. Neither a spring nor a damper corrects an incompatible mounting geometry or a door that binds.
Replacing and adjusting Lazy Susan cabinet hinges
Support the full door assembly before loosening any fastening. Photograph the original hinge positions, inspect the mounting material, and follow the removal and installation instructions for the selected hardware.
Once the correct hinge and plate are securely installed, check door height, side gaps and depth. Make small changes using the actual model’s adjustment controls, then gently test the complete opening and closing movement.
Stop if a screw spins without holding, a plate moves against the cabinet, or the door requires force. Damaged fixing holes, bent hardware and an incorrect hinge selection need repair or a fit correction—not more adjustment.
Common corner-door problems: what to check first
| Symptom | First checks | Avoid this shortcut |
|---|---|---|
| Doors bind or rub | Inspect the contact point, overlay, plate position and folding-joint geometry. | Forcing the door or changing hinge angle without checking fit. |
| Door will not close fully | Check obstructions, loose attachments, depth clearance and damaged hardware. | Assuming the soft-close damper is the cause. |
| Door drops after adjustment | Check screw holding, mounting material and hinge-to-plate engagement. | Repeatedly adjusting a hinge on an insecure mounting. |
| Handle hits a wall | Check the complete swing and a model-approved clearance or opening-limit solution. | Assuming any 135° hinge or restrictor clip will fit. |
Lazy Susan cabinet hinge FAQ
Are Lazy Susan cabinet hinges universal?
No. The door connection, cabinet construction, overlay, plate, drilling pattern and movement must match. A similar shape or the same cup diameter is not enough to establish compatibility.
Do I need a 135° or 165° hinge?
Start with the hinge’s job and the cabinet geometry, then compare the exact model specifications. Do not choose 135° merely because the space is tight, or 165° merely because you want greater access.
Can 135° and 165° hinges be used on the same cabinet?
A folding-door assembly can use different hinge types at different joints, provided they are designed to work in that arrangement. That does not establish compatibility between any two products or justify mixing mismatched hinges on the same joint.
Can I convert a Lazy Susan door to soft-close?
Potentially, when a compatible soft-close model is available for the required connection. Verify the complete fit, not just the angle and cup diameter. The conversion should not require forcing a door or using an incompatible mounting plate.
Do soft-close hinges always require deeper holes?
No. The two Berta 165° models shown here both list a 13 mm cup depth. Follow the exact model’s drilling instructions and check body clearance; do not deepen an existing bore merely because the replacement is soft-close.
Will these Berta hinges fit a face-frame cabinet?
The three linked products are listed for frameless, full-overlay applications. Do not assume direct compatibility with face-frame cabinetry. Confirm a hinge and mounting arrangement intended for your cabinet before ordering.
Not sure which corner hinge matches?
Send Berta Store photos of the open hinge, mounting plate and closed corner, along with your measurements and any part number. Identify the fit before committing to a replacement pack.
